Technical Specifications
Media: Water, Air, Oil (below 20cst)
Temperature: -5 -80℃
Mode of action: Pilot operated
Body material: Stainless Steel, Brass
Sealing material: NBR
Protection class: IP65
Pressure: N/C: 12bar; N/O: 8bar
Voltage: DC 24V, AC 220V, DC 12V, AC 110V
Function type: Normally Closed (N/C), normally Open (N/O)
Options
EPDM (E): suitable to water, hot water, gas, freon, MAX. 110℃;
In case you choose EPDM, please state “E” in your order.
Viton (V): suitable to hot water, acid, alkali, chemical salt, oil and hydrocarbon, MAX.130℃.
In case you choose Viton, please state “V” in your order.
